Office Layout DWG with Furniture and Electrical Plan
×
Posted By - Anju Singh
Posted By - Anju Singh
Description
This AutoCAD DWG file showcases a detailed office layout with an oval-shaped design, including a complete furniture and electrical layout plan. The floor plan features a double-height grand reception area, offices, meeting rooms, private cabins, and multiple workstations. Additionally, it displays the exact placement of electrical points along with a legend for easy reference. This file is an excellent resource for architects, interior designers, and space planners, offering a clear layout that can be adapted for a commercial project.
Show more
Product Details
| Category | Engineering & Technical Drawings |
| Software | Autocad DWG |
| File ID | 1721 |
| Type | Paid |
