Description
Discover this detailed AutoCAD drawing of a Pooja room, measuring 5’x8’ in height. The room features a back panel with MDF CNC cutting, offering a sophisticated aesthetic. The storage cabinetry includes two levels on the back panel: the first level has two vertical parts finished with decorative charcoal sheet or textured laminate, while the second level features MDF cutting finished with ducco paint. Additionally, the second level includes a horizontal ledge with a depth of 8”.
The cabinetry at the lower level extends 1’6” in depth and features a 2” thick Corian countertop. It incorporates four drawers on each side, with space in between for a stool, ottoman, or seating. A floating Corian counter/ledge is positioned above the drawer cabinetry. Aluminium profiles serve as handles for easy drawer access. A central hanging light is strategically placed to illuminate the space beautifully.
This drawing includes comprehensive working drawings and construction details, encompassing plans, elevations, sections, and detailed blow-up fixing instructions.
The cabinetry at the lower level extends 1’6” in depth and features a 2” thick Corian countertop. It incorporates four drawers on each side, with space in between for a stool, ottoman, or seating. A floating Corian counter/ledge is positioned above the drawer cabinetry. Aluminium profiles serve as handles for easy drawer access. A central hanging light is strategically placed to illuminate the space beautifully.
This drawing includes comprehensive working drawings and construction details, encompassing plans, elevations, sections, and detailed blow-up fixing instructions.
Show more
Product Details
Category | Religious Spaces |
Software | Autocad DWG |
File ID | 853 |
Type | Paid |
