Residential Tower CAD DWG- 3BHK Apartments Layout
×
Posted By - Shubham Bansal
Posted By - Shubham Bansal
Description
This AutoCAD DWG drawing features a detailed design of a residential tower, comprising three spacious 3BHK apartments. The drawing includes comprehensive layout and space planning for each apartment,door window schedule, shaft openings schedule, making it a valuable resource for architects, residential designers, and developers. Ideal for residential and commercial projects, this AutoCAD file provides essential details for efficient space utilization and effective design planning.
Show more
Product Details
| Category | Residential Spaces |
| Software | Autocad DWG |
| File ID | 1021 |
| Type | Paid |
