Wardrobe Design in Autocad- Plan and Elevation Views
×
Posted By - Siya Ambani
Posted By - Siya Ambani
Description
Discover the detailed Autocad drawing of a wardrobe/cupboard, expertly designed with dimensions of 3'x2'x8'H. This comprehensive drawing showcases three different internal partition arrangements, providing versatile storage solutions. The drawing includes both plan and elevation views, making it an invaluable resource for architects and designers looking to create efficient and stylish wardrobe spaces.
Show more
Product Details
| Category | Furniture & Fixtures |
| Software | Autocad DWG |
| File ID | 625 |
| Type | Paid |
