14'x14' False Ceiling Design DWG (Wood and Gypsum Board)
Download this detailed AutoCAD drawing of a designer false ceiling for a 14'x14' room, crafted from plaster of Paris or gypsum board. The ceiling features a three-level design: the first level aligns with the beam bottom, the second level is 2 inches below the beam bottom, and the third level is 4 inches below the beam bottom.
The ceiling design includes an offset (highlighted in grey at the 4" level) around all edges with cove lighting behind it and in the center. The central part (highlighted in brown at the 2" level) is finished with wooden or wood-finished materials like laminate, PVC, or HPL, with a fan provision in the center. The white areas are at the beam bottom level (level 0). Rectangular ceiling lights enhance the overall design. This drawing includes working drawings and construction details with plans, elevations, sections, and all necessary blow-up fixing details.
The ceiling design includes an offset (highlighted in grey at the 4" level) around all edges with cove lighting behind it and in the center. The central part (highlighted in brown at the 2" level) is finished with wooden or wood-finished materials like laminate, PVC, or HPL, with a fan provision in the center. The white areas are at the beam bottom level (level 0). Rectangular ceiling lights enhance the overall design. This drawing includes working drawings and construction details with plans, elevations, sections, and all necessary blow-up fixing details.
Show more
Downloads in last 24 hours
Product Details
| Category | Construction & Standard Details |
| Software | Autocad DWG |
| File ID | 406 |
| Type | Paid |
