Description
Download this detailed AutoCAD drawing of an office cabin area measuring 10'9" x 9'. This well-planned space includes a working area and a small seating space. Wall A and Wall B feature horizontally placed wooden planks of varying lengths, finished with laminate. These wooden planks are wall-mounted and include open shelves with a depth of 10" and a length of approximately 4'.
The cabin includes a table measuring 5' x 1'8" x 2'6" (H) with an L-shaped tabletop extending to the floor. Additionally, a small side storage table is attached to the main table, providing open spaces and drawers. The back storage unit offers ample storage with shelves and drawers. The front face of the table features the same wooden plank pattern as the wall panels but is vertically placed.
This AutoCAD DWG file includes working drawings and construction details, covering the plan, elevations, sections, and all necessary blow-up fixing details. Ideal for architects and interior designers, this file provides a complete office cabin interior design solution.
The cabin includes a table measuring 5' x 1'8" x 2'6" (H) with an L-shaped tabletop extending to the floor. Additionally, a small side storage table is attached to the main table, providing open spaces and drawers. The back storage unit offers ample storage with shelves and drawers. The front face of the table features the same wooden plank pattern as the wall panels but is vertically placed.
This AutoCAD DWG file includes working drawings and construction details, covering the plan, elevations, sections, and all necessary blow-up fixing details. Ideal for architects and interior designers, this file provides a complete office cabin interior design solution.
Show more
Product Details
Category | Commercial and Retail Hubs |
Software | Autocad DWG |
File ID | 32 |
Type | Paid |
